A wooden hearth tool stand is a compact project, but its routed handle slots need enough clearance to hold tools without letting them tip or bind. This plan makes a stand for four common fireplace tools, with a stable base, a slotted upright, and a removable drip tray. Adjust the slot spacing to suit your own handles before cutting.
Contents
Dimensions and materials
The example stand is 18 inches tall, 10 inches wide, and 8 inches deep. It holds four tools with handles up to about 1¼ inches in diameter. Use those dimensions as a starting point, not a fixed pattern: measure your tools, then leave at least ⅜ inch between neighboring handles so they can be lifted out without catching.
For the upright and base, use straight, dry hardwood such as oak, maple, or ash. A ¾-inch-thick board is adequate for the upright; make the base from 1-inch stock or laminate two pieces of ¾-inch stock. Hardwood is more resistant to dents than pine, but clear, knot-free softwood can work if the stand will see light use. Avoid wood with checks or loose knots near the routed slots, where the narrow webs between openings are most vulnerable.
You will also need wood glue, four screws, sandpaper, and a finish suitable for occasional contact with warm tools. A steel or stainless drip tray is a practical addition because wet ash and moisture can stain wood. Search for a fireplace tool drip tray sized to fit your base, or make a removable tray from sheet metal.
Tools and slot options
A router with a straight bit makes repeatable, clean slots, but a drill and jigsaw can do the job if you are patient with the layout and sanding. A router table is convenient for short workpieces, though routing the upright flat on a bench with a guide fence is often easier to control.
| Method | Best for | Trade-off |
|---|---|---|
| Router and template or fence | Even, consistent slots | Requires careful setup and shallow passes |
| Drill and jigsaw | One-off builds with basic tools | Slot ends need more cleanup; edges may be less uniform |
| Drill press and hole saw | Rounded slot ends | Hole size limits the shape and requires accurate spacing |
If you need to buy a router for this and other shop work, compare compact wood routers. For this stand, a basic fixed-base router is enough; spending more for a large plunge router is hard to justify unless you already have other jobs for it.
Cut the parts
Cut the upright to 18 by 10 inches and the base to 10 by 8 inches. If your chosen drip tray is wider, increase the base depth or width so the tray sits fully supported. Mark the front of the upright and the centerline of each tool position. For four slots across a 10-inch panel, place the slot centers roughly 2 inches apart, leaving about 1½ inches from each outer center to the edge. Check that this spacing suits your handles and the width of your tools’ heads.
Each slot in this plan is 1½ inches long and ⅜ inch wide, with rounded ends. This fits many handles while leaving substantial wood between adjacent openings. If your handles are thicker, widen the slots only as much as needed; avoid making the narrow bridges between slots less than ¾ inch. Mark each slot’s ends with a center punch or awl so they remain easy to locate after clamping.
Route the handle slots
Clamp the upright flat to a stable bench, with scrap backing beneath it to reduce tear-out. Make a simple template from ¼-inch plywood or hardboard with one accurately cut slot. Clamp or secure it so it cannot shift. A guide bushing works with a template; a straightedge fence works if you are routing directly from layout lines.
Drill a ⅜-inch hole at each end of every slot. These holes establish the rounded ends and give the router a safe starting and stopping point. With a straight bit of the same diameter, route between the holes in two or three shallow passes rather than trying to remove the full ¾-inch thickness at once. Keep the router base flat and move steadily. Test the setup on scrap of the same thickness first.
With a drill-and-jigsaw method, drill the end holes, cut between them just inside the lines, then bring the edges to the marks with a rasp and sandpaper wrapped around a dowel. Do not force the blade around the slot ends; tight turns can bend it and leave an uneven opening. Whichever method you use, ease the slot edges with a small roundover bit or hand sanding. Sharp edges chip more easily and can scrape painted or wooden handles.
Assemble the stand
Center the upright on the base, leaving equal space at each side and placing its back edge about ½ inch from the rear of the base. Check the stand’s balance with the heaviest tool hanging in an outside slot. If it rocks or tips, widen the base before assembly; adding weight can help, but a larger footprint is usually the simpler fix.
Drill two pilot holes through the base into the upright, keeping them clear of the routed slots. Apply a thin, even coat of wood glue, then fasten with two screws from underneath. Use screws long enough to engage the upright by about 1 inch without breaking through its front face. Wipe away squeeze-out and verify the upright is square before the glue sets. A removable tray can sit on the base; if you want it fixed in place, use small metal clips rather than glue so it can be removed for cleaning.
Sand, finish, and test
Sand the surfaces through 120 and 180 grit, rounding exposed corners slightly. Remove dust before applying a finish. A water-based polyurethane or hardwax oil protects against fingerprints and occasional dampness; neither makes the stand fireproof. Keep the stand outside the fireplace opening and away from direct flame, and do not park hot tools against bare wood. If sparks or hot embers may reach the stand, use a metal holder instead.
Let the finish cure for the maker’s stated time before loading the tools. Test each slot with its handle, then lift the tools out and return them several times. If a handle sticks, sand the slot gradually rather than widening every opening. Check stability again with the heaviest tool in the outermost slot, and empty the tray regularly so ash and moisture do not sit against the wood.
